General

Model

CPC(D)10X

CPC(D)15X

CPC(D)18X

CPQ(D)10

CPQ(D)15

CPQ(D)18

CPC(D)10W

CPC(D)15W

CPC(D)18W

Power type

Diesel

Gasoline  LPG

Rated capacity

kg

1000

1500

1750

1000

1500

1750

Load center

mm

500

500

Dimensions

Lift height

mm

3000

3000

Free lift height

mm

164

164

Fork size

mm

920×100×40

1070×120×40

920×100×40

1070×120×40

Mast tilt angle

deg

6/12

6/12

Front overhang

mm

436

436

Overall

Overall length

Without fork

mm

2180

2235

2270

2180

2235

2270

dimensions

With fork

3116

3171

3356

3116

3171

3356

Overall width

Wheel width

mm

1095

1095

Frame width

1080

1080

Mast lowered height

mm

1995

1995

Mast extended height

mm

4030

4038

Overhead guard height

mm

2075

2075

Turning radius

mm

1890

1960

2000

1890

1960

2000

Min. right angle aisle width

mm

1720

1780

1820

1720

1780

1820

Performance

Travel speed

Hydraulic

km/h

14.5/13.5

14.5/13.5

(no load/full load)

Mechanical

Shift Ⅰ

6/5.5

6/5.5

Shift Ⅱ

14/13.5

14/13.5

Lift speed (no load/full load)

mm/sec

510/450

510/450

Max. grade ability

%

20

20

Self weight

kg

2340

2740

2943

2340

2740

2943

Wheel & Tires

Tires

Front

6.50-10-10PR

6.50-10-10PR

Rear

5.00-8-8PR

5.00-8-10PR

5.00-8-8PR

5.00-8-10PR

Tread

Front

mm

890

890

Rear

mm

920

920

Wheelbase

mm

1400

1400

Ground clearance(full load/no load)

Mast

mm

95/105

85/105

95/105

85/105

Frame

105/115

105/115

Drive units & control

Engine

Apply to truck model

CPC(D)10/15/18X

CPC(D)10/15/18W

CPQ(D)20/25/30   CPY(D)20/25/30

Model

NB485BPG

ISUZU C240PKJ

MITSUBISHI

MITSUBISHI

Rated output

kw/rpm

30/2600

34.5/2500

25/2400

32.3/2300

Rated torque

N.m/rpm

131/1800

139/1800

113/1600

142/1600

No. of cylinder

4

4

4

4

Bore×stroke

mm

85×100

86×102

87.2×83

87.2×83

Displacement

L

2.27

2.369

1.486

1.982

Lubrication oil capacity

L

7

5.2

3.8

3.8
