| Generals |
Model |
|
CPC(D)30-X |
CPC(D)35-X |
CPQ(D)30-H |
CPQ(D)35-H |
| CPC(D)30-W |
CPC(D)35-X |
CPY(D)30-H |
CPY(D)35-H |
| Power type |
|
Diesel |
Gasoline |
| Rated capacity |
kg |
3000 |
3500 |
3000 |
3500 |
| Load center |
mm |
500 |
500 |
| Dimensions |
Lift height |
mm |
3000 |
3000 |
| Free lift height |
mm |
145 |
145 |
| Fork size N〜U〜L |
mm |
1070*125*45 |
1070*130*45 |
1070*125*45 |
1070*130*45 |
| Fork outside spread Min./Max. |
mm |
300/1700 |
300/1700 |
| Mast tilt angle α / β |
deg |
6/12 |
6/12 |
| Front o-verhang G |
mm |
501 |
501 |
| Overall |
Length to face of fork J |
mm |
2720 |
2720 |
| dimensions |
Overall width Q |
mm |
1225 |
1225 |
| |
Mast lowered |
mm |
2070 |
2070 |
| |
height C |
| |
Mast extended height A |
mm |
4272 |
4272 |
| |
Overhead guard height P |
mm |
2090 |
2090 |
| Turning radius W |
mm |
2460 |
2540 |
2460 |
2540 |
| Min. right angle aisle width X |
mm |
2110 |
2190 |
2110 |
2190 |
| Performance |
Travel speed (full load/no load) |
Hydraulic |
km/h |
17/19 |
18/19 |
| Mechanical |
1 |
8.8/9 |
8.5/9 |
| 11 |
18.5/20 |
18.5/19 |
| Lift speed with load |
mm/sec |
400 |
360 |
400 |
360 |
| Max. gradeability |
% |
18 |
15 |
18 |
15 |
| Self weight |
kg |
4380 |
4750 |
4380 |
4750 |
| Wheel & Tires |
Tires |
Front |
|
28*9-15-14PR |
28*9-15-14PR |
| Rear |
|
6.50-10-10PR |
6.50-10-10PR |
| Tread |
Front Q |
mm |
1000 |
1000 |
| Rear S |
mm |
970 |
970 |
| Wheelbase |
MM |
1700 |
1700 |
| Ground clearance(no load/full load) |
Mast M |
mm |
110/135 |
110/135 |
| Frame F |
130/135 |
130/135 |
| Drive units & control |
Battery |
V/AH |
2*12/100 |
2*12/100 |
| Engine |
Apply to truck model |
|
CPC(D) |
CPC(D) |
CPC(D)30w1 |
CPC(D) |
CPC(D) |
CPQ(D)30/35H1 |
CPQ(D)30/35H4 |
| 30/35x1 |
35x2 |
30/35w2 |
30/35w3 |
CPQ(Y)30/35H1 |
CPQ(Y)30/35H4 |
| Model |
|
490BPG |
495BPG |
ISUZU |
ISUZU |
HJ493 |
MITSUBISHI4G64 |
HW491 |
| C240PKJ |
4JG2 |
| Rated output |
kw/rpm |
37/2650 |
42/2650 |
34.5/2500 |
44.9/2450 |
39/2500 |
37/2500 |
42/2400 |
| Rated torque |
N.m/rpm |
148/1900 |
174/ |
139/1800 |
186.3/ |
165/1800 |
161/1600 |
161/1800 |
| 1800-2000 |
1600-1800 |
| No.of cylinder |
|
4 |
4 |
4 |
4 |
4 |
4 |
4 |
| Bore〜stroke |
mm |
90*100 |
95*105 |
86*102 |
95.4*107 |
92*93 |
86.5*100 |
91*86 |
| Displacement |
L |
2.54 |
2.98 |
2.369 |
3.059 |
2.771 |
2.35 |
2.237 |
