| General |
Model |
|
CPCD40-L |
CPCD45-L |
CPCD50-L |
CPCD40-LF |
CPCD45-LF |
CPCD50-LF |
| Power type |
|
Diesel |
| Rated capacity |
kg |
4000 |
4500 |
5000 |
4000 |
4500 |
5000 |
| Load center |
mm |
500 |
500 |
| Dimensions |
Lift height |
mm |
3000 |
3000 |
| Free lift height |
mm |
150 |
150 |
| Fork size |
mm |
1070×150×55 |
1070×150×55 |
| Fork spread outside |
Min./Max. |
mm |
300/1200 |
300/1200 |
| Mast tilt angle |
deg |
6°/12° |
6°/12° |
| Front overhang |
mm |
562 |
562 |
| Overall |
Length to face of fork |
mm |
3091 |
3091 |
3125 |
3091 |
3091 |
3125 |
| dimensions |
Length with fork |
mm |
4182 |
4182 |
4216 |
4182 |
4182 |
4215 |
| |
Overall width |
mm |
1485 |
1480 |
| |
Wheel width |
mm |
1465 |
1465 |
| |
Mast lowered height |
mm |
2380 |
2380 |
| |
Mast extended height |
mm |
4250 |
4250 |
| |
Overhead guard height |
mm |
2290 |
2290 |
| Turning radius |
mm |
2790 |
2790 |
2790 |
2830 |
| Min, right angle aisle width |
mm |
3415 |
3415 |
3460 |
3415 |
3415 |
3460 |
| Performance |
No load/full load |
Travel speed |
Forward Ⅰ |
km/h |
15/14 |
15/14 |
| Forward Ⅱ |
22/20 |
22/20 |
| Backward Ⅰ |
15/14 |
15/14 |
| Lift speed |
mm/sec |
480/450 |
480/450 |
480/430 |
480/450 |
480/450 |
480/430 |
| Max. gradeability |
% |
20/19 |
18/17 |
17/16 |
20/19 |
18/17 |
17/16 |
| Max. drawbar pull |
KN |
21 |
21 |
| Self weight |
kg |
6450 |
6770 |
7050 |
6450 |
6770 |
7050 |
| Wheel & Tire |
Tires |
Front |
|
300-15-18PR |
300-15-18PR |
| Rear |
|
7.00-12-12PR |
7.00-12-12PR |
| Tread |
Front |
mm |
1180 |
1180 |
| Rear |
mm |
1190 |
1190 |
| Wheelbase |
mm |
2000 |
2000 |
| Min.ground clearance |
Mast |
mm |
175/145 |
175/145 |
| (no load/full load) |
Frame |
190/180 |
190/180 |
| Drive units & control |
Battery |
V/AH |
2-12V/80AH |
2-12V/80AH |
| Engine |
Model |
|
A-6BG1QC-05 |
R4105G25 |
| Rated output |
kw/rpm |
68/2000 |
59/2300 |
| Rated torque |
N.m/rpm |
340/1400～1600 |
280/1600～1800 |
| No.of cylinder |
|
6 |
4 |
| Bore×stroke |
mm |
105×125 |
105×120 |
| Displacement |
cc |
6494 |
4156 |
| Fuel tank capacity |
L |
90 |
90 |
| Transmissions |
Type |
|
Hydraulic |
Hydraulic |
| Shift |
FWD/RWD |
|
2/1 |
2/1 |
| |
Operating pressure |
Mpa |
17 |
17 |
18 |
17 |
17 |
18 |
