general	model				CPD10	CPDS18
	rated capacity			kg	1000	1500
	load center			mm	500
	power type				battery
dimensions	lift height			mm	3000	3000
	free lift height			mm	164	164
	fork size			mm	920×120×40	920×120×40
	fork outside spread(min./max.)			mm	200/950
	mast tilt angle(forward/backward)			deg	6/12
	overal dimensions	length to face of fork		mm	2056	2056
		overall width		mm	1080
		mast lowered height		mm	1995
		mast extended height		mm	4038
		overhead guard height		mm	2162
	turning radius			mm	1820
	front overhang			mm	436
	min.right angle aisle width			mm	1810
	min.right angle stacking aisle width			mm	3370	3370
performance	no load/full load	travel speed		km/h	13.5/11.5	13/11
		lifting speed		mm/sec	400/300	390/285
	max.grade ability			%	15
	self weight			kg	2900	3120
	max.pull force(full load)			KN	6	6.5
wheel&tires	tyres	front			6.50-10-10pr
		rear			5.00-8-8pr
	tread	front		mm	890
		rear		mm	920
	ground clearance	mast		mm	80/85	75/85
		frame		mm	105/95
	wheelbase			mm	105/95
power&control	battery	model			24-D-440（24-D-480）
		voltage		V/Ah	48
		weight		kg	720/744
	motor	drive motor	model		XQ-5-3A1
			rated power	KW	5.3(an hour)
		lift motor	model		XQD-8.2-1
			rated power	kw	8.2(fifteen minutes)
	controller				GE separate excitation controller
